APC PDPM144F power distribution unit (PDU) Black
APC PDPM144F power distribution unit (PDU) Black
APC PDPM144F. PDU types: Monitored, Product color: Black. Management platform: Web/SNMP/Telnet. Nominal input voltage: 208 V, AC input frequency: 60 Hz, Nominal output voltage: 208 V. Certification: UL. Width: 11.8" (300 mm), Depth: 42.4" (1077 mm), Height: 78.8" (2002 mm)
APC Modular Remote Power Panel, 144kW, 400A, 208V, 72 Pole, 300mm
A fully scalable power distribution system that cost-effectively provides high levels of availability and enables the addition of circuits and cord-sets without requiring you to schedule outages or conduct dangerous hot work.
UL-listed Touch-safe backplane
Adding Power Distribution Modules requires no hot work; one trained user can safely add new modules without removing power to the existing PDU load
Industry-leading power density
High-density power distribution in a sleek 300mm enclosure
Multiple distribution options
Superior design flexibility enables a wide range of customer requirements to be addressed.
UL-listed Touch-safe backplane
Adding Power Distribution Modules requires no hot work; one trained user can safely add new modules without removing power to the existing PDU load
Multiple distribution options
Superior design flexibility enables a wide range of customer requirements to be addressed.
Toolless installation of breakers
Install factory-assembled Power Distribution Modules in under ten minutes - no tools are required
Safety
Enhance user safety with isolation at all touch points and with positive locking mechanisms that reduce the risk of accidental disconnection
Current Monitoring
Monitors the aggregate current draw per power distribution unit.
Network management capability
Full-featured network management interfaces that provide standards-based management via Web, SNMP, and Telnet.
Ease of system expansion
Power Distribution Modules provide an option to expand power distribution capability as power demands increase.
System mobility
PDU equipment can easily be relocated to accommodate a changing data center environment.
Smallest footprint
Minimizes your real estate expenses
Modular design
Provides fast serviceability and reduced maintenance requirements via self-diagnosing, field-replaceable modules.
